This Semi-automatic Cryostat Microtome combines advanced and patented technology which is a wise choice for histopathology research.
It is ready when you are. Chamber temperature can drop within 60 minutes of turning the unit on. The stand-by mode can be controlled between -10°C and -40°C automatically. The system returns to working temperature within 15 minutes of initiation from stand-by mode.
Technical Specifications of Semi-automatic Cryostat Microtome
Section thickness setting range: 0-100um
Trimming thickness setting range: 10-400um
■Freezing chamber temperature range: -10℃～-30℃ ■cooling down time to -30℃: 60 min ■Freeze shelf minimum temperature: -45℃ ■Lowest temperature of peltier unit on freeze shelf: -55℃ ■Peltier working time: 15 minutes ■Maximum specimen size: 35mm x35mm ■Vertical stroke: 60mm,Object feed: 20mm ■Coarse feeding speed: 0.7mm/s; 0.35mm/s ■Retraction range: 0～80μm adjustable; in 5μm increment ■Voltage and frequency: AC220~10% 50HZ(Standard) Special requirement may customize by order ■Power : 600VA ■Dimension(WX DX H): 650x805x1160mm ■Net weight: 115kg
■It is designed under overall engineering and ergonomic concept.All the components are processed with computer;
■This model has an ergonomic design and is manufactured using numerically-controlled machine tools; ■A specimen retraction function protects the specimen from blade damage; ■A trim button allows for easy switching between trim and sectioning mode; ■ Includes a counting function for the number of sections and the total thickness; ■The cryogenic refrigeration system utilizes a forced cooling structure. The refrigeration chamber, freezing shelf, blade holder, and specimen holder are cooled independently by a German double compressor to enhance cooling performance and increase cooling speed. ■Imported R404A non-CFC refrigerants that are environment-friendly; ■Achieves the desirable sectioning temperature within 20 minutes after turning on the unit when using the fast cooling mode; ■UV option enables surface disinfection of harmful bacteria, viruses, and spores by using 35 min after each use; It also has low-voltage DC shadowless lamp; ■Semiconductor cooling function can be turned on and off; ■Hearable and removable glass door; ■Two defrosting modes: time defrosting and manual defrosting; ■Microtome is outside of the refrigeration chamber to avoid the effect of heat-expansion and cold-contraction, thus minimizing the need for maintenance; ■User-friendly intelligent operational interface is easy to learn and operate; ■LCD screen displays the number of sections and the total thickness, section thickness, specimen retraction value, temperature setting, date, time, temperature and on/off timer are all included on the main display; ■Auto sleep function results in longer compressor life: the cryo-chamber temperature automatically stays in a range of -1 to -9℃ under the sleep mode, and returns to the sectioning temperature within 15 minutes after canceling the sleep mode; ■Keyboard locking function to avoid accident misoperation; ■A mechanical hand-wheel lock ensure safe chamber access, 16 position for locking; ■The red bar on the blade holder covers the whole length of blade to protect the user and the push bar enables easy changing of the blade; ■A large-size quick-freezing shelf allows for the preparation of 17 specimens at the same time; Two holes for semiconductor refrigeration; ■It has cleaning device, easy help customer to clean the unit; ■Specimen Orientation: XY – 8°; Z– 360° adjustable at any orientations to ensure precise placement; ■Self-detection function for the temperature senor, can help to warn the failure on temperature senor.
